Features
Ultra-fast Maximum Power Point Tracking (MPPT)
Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.
Advanced Maximum Power Point Detection in case of partial shading conditions
If partial shading occurs, two or more maximum power points (MPP) may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP.
Outstanding conversion efficiency
No cooling fan. Maximum efficiency exceeds 99%.
Flexible charge algorithm
Fully programmable charge algorithm, and eight preprogrammed algorithms, selectable with a rotary switch (see manual for details).
Extensive electronic protection
Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection.
Internal temperature sensor
Compensates absorption and float charge voltage for temperature.
Optional external battery voltage, temperature and current sensing via Bluetooth
A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature (and current, in case of a BMV 712 or a SmartShunt) to one or more BlueSolar Charge Controllers. (VE.Direct Bluetooth Smart dongle needed)
VE.Can: the multiple controller solution
Up to 25 units can be synchronised with VE.Can
VE.Direct or VE.Can
For a wired data connection to a Color Control GX, other GX products, PC or other devices
Remote on-off
To connect for example to a VE.BUS BMS.
Programmable relay
Can be programmed to trip on an alarm, or other events.
Optional: SmartSolar pluggable LCD display
Simply remove the rubber seal that protects the plug on the front of the controller, and plug-in the display.
| Brand |
Victron Energy |
|---|---|
| Manufacturer Part Number |
SCC125070441 |
| GTIN |
8719076050889 |
| Battery Voltage |
12/24/48V Auto Select (36V: manual) |
| Rated Charge Current |
70A |
| Nominal PV Power, 12V |
1000W |
| Nominal PV Power, 24V |
2000W |
| Max. PV Short Circuit Current |
35A |
| Maximum PV Open Circuit Voltage |
250V absolute maximum coldest conditions | 245V start-up and operating maximum |
| Efficiency |
99% |
| Charge Algorithm |
multi-stage adaptive (eight preprogrammed algorithms) or user defined algorithm |
| Data Communication Port |
VE.Can |
| IP Rating |
IP43 (electronic components), IP22 (connection area) |
| Dimensions |
H185 x W250 x D95mm |
| Weight |
3Kg |
| Warranty |
5 Years |
