Features
- Lighting control function, fully programmable.
- Three stage battery charging (bulk, absorption, float), fully programmable.
- Integrated battery monitor function (Remote Panel needed to display state of charge).
- Load output with low voltage disconnect and manual control (default setting).
- Optional external temperature sensor. – Load output protected against over load and short circuit.
- Protected against reverse polarity connection of the solar array and/or battery.
Day/night timing options
See Remote Panel manual for details
| Brand |
Victron Energy |
|---|---|
| Manufacturer Part Number |
SCC010020110 |
| GTIN |
8719076025382 |
| Battery Voltage |
12/24V with automatic system voltage detection |
| Rated Charge Current |
20A |
| Maximum Solar Voltage |
28V / 55V |
| Load Output |
Manual control + low voltage disconnect + timer |
| Grounding |
Common positive |
| IP Rating |
IP30 |
| Dimensions |
H160 x W82 x D48mm |
| Weight |
0.3Kg |
| Warranty |
5 Years |
